Professional Wifi Car Diagnostic Tool KW903 For 12V Gasoline And Diesel Cars

 Item size( cm):

package size (cm):12*7.5*4
Item Net weight(kgs):0.03
Package Gross weight(Kg):0.084
qty/cn: 100pcs/ cn,
Carton size : 39*25.5*36CM,
Carton Weight : 8.9KG/ carton
Product Description

 car diagnostic machine WIFI KW903 Red Black Color ABS material Detect 12V gasoline and diesel cars







Features:

              KW903 able to detect and interpret these protocols automatically.

              It also provides support for high speed communications and a low power sleep mode.

It use AT commands to communicate with a host device (PC, notebook, iPhone, iPod touch, iPad and so on).



               There are plenty of software packages available, which are fully compatible with KW903.

Some of them have pretty useful features, such as engine running parameters monitoring, DTC reading and clearing, MPG meter, etc.



               You can even write your own software on a specified hardware platform if you wish, because the AT commands are fully documented and very well explained.KW903 measuring only 2.7 x 1.25x 0.9 inches, and it comes attached with a 6 ft OBDII cable for easy installation.

It also comes included with a power switch built-in to prevent the need for having to constantly disconnect your unit from the OBDII port.



               It is compatible with 1996 and later vehicles Connecting to your iPhone / iPod touch is made by WIFI connection in adHoc mode.









Colour Choice :

6 Color from Black White/ White Red/Black / Black Orange/Black Red/ Red





Language :

English is default language, please select the language you need on phone settings interface





Specifications:



Range: 50 ft (Line of sight)

Antenna: Internal

Power Consumption: 0.75 Watts (With Power Switch)

Wifi Standard: 802.11a/b/g

Operating Temperature: -15 to 100 Deg Celsius

Plastic: Automotive Grade

Dimensions: 2.75 x 1.25 x 1.2 inches

Connection Type: Wifi



Package includes:



1x KW903 WIFI Scanner

1x Software CD

1x English User Manual



Packing infomation :



Item size( cm):
package size (cm):12*7.5*4
Item Net weight(kgs):0.03
Package Gross weight(Kg):0.084
qty/cn: 100pcs/ cn,
Carton size : 39*25.5*36CM,
Carton Weight : 8.9KG/ carton









Connect type :

Wifi for android and iphone

















With proper software installed in the host device, you may have following parameters read out from your vehicle,Below is

Function :

  • Vehicle Speed
  • RPM
  • Fuel Consumption*
  • Engine Coolant Temp
  • Fuel Pressure
  • Calculated Engine Load
  • Throttle Position
  • Intake Manifold Pressure
  • Air Intake Temp
  • Timing Advance
  • Mass Air Flow
  • Fuel Level
  • Barometric Pressure
  • EVAP System Vapor Pressure
  • Fuel Trim
